Technical Details
Frameset
Frame:
Lightweight aluminium with Powder Coat Finish | 1 1 / 8" head tube | 140mm post mount | 9 x 135mm QR
Fork:
Lightweight Aluminium with Powder Coat Finish | 140mm Post Mount | 9 X 100mm QR
Cockpit
Stem:
40mm Length | 6° Angle
Handlebar:
SDG Slater Handlebar
Seat
Seatpost:
Alloy | 27.2mm
Saddle:
SDG Fly Jr
Drivetrain
Crankset:
Sunrace
Chainrings:
11-34T
Cassette:
Sunrace
Cassette Size:
11-34T
Chain:
SRAM
Front Derailleur:
SRAM X4
Rear Derailleur:
SRAM X4 Trigger
Shifters:
SRAM X4 Trigger
Gears:
1 x 8
Bottom Bracket:
BSA Threaded Bottom Bracket
Brakes
Brake Levers / Calipers:
TEKTRO HD-M286 | Short Reach Levers
Rotors:
TEKTRO TR140-22
Rotor Size (F/R):
140mm
Wheels
Rims:
DD32
Hubs (F/R):
CNC Machined Alloy | Sealed Bearings | Quick Release
Tires:
Kenda Booster | 24 x 2.4"
Additional Information
Tire Clearance:
58mm
ASTM Classification:
Level 3
System Weight Limit:
60kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | 24 |
|---|---|
| Rider Height | 120-145 |
| Reach | 350 |
| Stack | 507 |
| Bar Drop | |
| Bar Reach | |
| Bar Rise | 20 |
| Bar Sweep | 5 |
| Bar Width | 650 |
| Base Bar Drop Flat Cockpit | |
| Base Bar Drop V-Cockpit | |
| Base Bar Reach Flat Cockpit | |
| Base Bar Reach V-Cockpit | |
| BB Drop | 40 |
| BB Drop (SLACK) | |
| BB Drop (STEEP) | |
| BB Height (SLACK) | |
| BB Height (STEEP) | |
| Chainstay | |
| Crank Length | 140 |
| LT | BB Drop (SLACK) | |
| LT | BB Drop (STEEP) | |
| LT | BB Height (SLACK) | |
| LT | BB Height (STEEP) | |
| LT | Chainstay | |
| LT | Fork Length | |
| LT | Fork Rake | |
| LT | Frame Size | |
| LT | Front Center (SLACK) | |
| LT | Front Center (STEEP) | |
| LT | Head Tube | |
| LT | HT Angle (SLACK) | |
| LT | HT Angle (STEEP) | |
| LT | Reach (SLACK) | |
| LT | Reach (STEEP) | |
| LT | Rider Height | |
| LT | Seat Tube | |
| LT | ST Angle @750mm Saddle Height (SLACK) | |
| LT | ST Angle @750mm Saddle Height (STEEP) | |
| LT | ST Angle Actual (SLACK) | |
| LT | ST Angle Actual (STEEP) | |
| LT | ST Angle Effective (SLACK) | |
| LT | ST Angle Effective (STEEP) | |
| LT | Stack (SLACK) | |
| LT | Stack (STEEP) | |
| LT | Stand Over Height (80 in Front of BB) | |
| LT | Stand Over Height (Lowest Point) | |
| LT | Top Tube (SLACK) | |
| LT | Top Tube (STEEP) | |
| LT | Wheelbase (SLACK) | |
| LT | Wheelbase (STEEP) | |
| ST | BB Drop (SLACK) | |
| ST | BB Drop (STEEP) | |
| ST | BB Height (STACK) | |
| ST | BB Height (STEEP) | |
| ST | Chainstay | |
| ST | Fork Length | |
| ST | Fork Rake | |
| ST | Frame Size | |
| ST | Front Center (SLACK) | |
| ST | Front Center (STEEP) | |
| ST | Head Tube | |
| ST | HT Angle (SLACK) | |
| ST | HT Angle (STEEP) | |
| ST | Reach (SLACK) | |
| ST | Reach (STEEP) | |
| ST | Rider Height | |
| ST | Seat Tube | |
| ST | ST Angle @750mm Saddle Height (SLACK) | |
| ST | ST Angle @750mm Saddle Height (STEEP) | |
| ST | ST Angle Actual (SLACK) | |
| ST | ST Angle Actual (STEEP) | |
| ST | ST Angle Effective (SLACK) | |
| ST | ST Angle Effective (STEEP) | |
| ST | Stack (SLACK) | |
| ST | Stack (STEEP) | |
| ST | Stand Over Height (80 in Front of BB) | |
| ST | Stand Over Height (Lowest Point) | |
| ST | Top Tube (SLACK) | |
| ST | Top Tube (STEEP) | |
| ST | Wheelbase (SLACK) | |
| ST | Wheelbase (STEEP) | |
| Fork Length | 412 |
| Fork Rake | 40 |
| Frame Size | |
| Front Center | 538 |
| Front Center (SLACK) | |
| Front Center (STEEP) | |
| Head Tube | 105 |
| Head Tube Angle | 68 |
| HT Angle (SLACK) | |
| HT Angle (STEEP) | |
| Pad Reach Flat Cockpit | |
| Pad Reach V-Cockpit | |
| Pad Stack Flat Cockpit | |
| Pad Stack V-Cockpit | |
| Reach (SLACK) | |
| Reach (STEEP) | |
| Rear Center | 392 |
| Saddle Height Range | |
| Seat Angle | 73 |
| Seat Tube | 300 |
| Seatpost Drop | |
| Seatpost Length | 300 |
| Seatpost Offset | 15 |
| ST Angle @750mm Saddle Height (SLACK) | |
| ST Angle @750mm Saddle Height (STEEP) | |
| ST Angle Actual (SLACK) | |
| ST Angle Actual (STEEP) | |
| ST Angle Effective (SLACK) | |
| ST Angle Effective (STEEP) | |
| Stack (SLACK) | |
| Stack (STEEP) | |
| Stand Over Height (80 in Front of BB) | |
| Stand Over Height (Lowest Point) | |
| Standover Height | 580 |
| Stem Angle | ±6 |
| Stem Length | 35 |
| Top Tube | 505 |
| Top Tube (SLACK) | |
| Top Tube (STEEP) | |
| Trail | 82 |
| Wheelbase | 972 |
| Wheelbase (SLACK) | |
| Wheelbase (STEEP) |
